Description
♦ Machine is used to roll groove on both steel pipe and lining plastic pipe.
♦ Installation and discharging of machine is easy, which could be done by one person. And machine is easy to be moved.
♦ Equipped with integral hydraulic system and stroke limitation device.
♦ Machine is equipped with one set of pipe supporter, which is to support workpiece to make operation easy.
Specifications
Main Parameters |
Paramters Content |
Pipe Capacity |
Steel pipe: 2″-6″(Φ57-Φ168mm);Lining plastic pipe: 2″-3″(Φ57-Φ89mm) |
Max Wall Thickness |
6mm |
Output Power |
550W |
Efficient Speed |
24 RPM |
Voltage |
220V, single phases, or customized |
Frequency |
50Hz or 60Hz |
Gross/Net Weight |
80/66Kg |
Packing Size |
970x580x630mm |
