The NEW generation of FMT electronic flow meters from TECALEMIT impresses with its robust versatility for use with a wide range of liquids.
The FMT 3 Flow Rate Meter with illuminated digital display for streaming liquids utilizing the measurement principle of a turbine wheel counter is suitable for diesel/fuel oil, AdBlue®, radiator antifreeze and water.
The two-line LED display shows the current dispensation values and the total stored volume or 8 partial stored volumes. The display can be mounted to fit the viewing angle or moved about even after being installed.
The symmetric measurement chamber allows the device to be used with all flow directions. The measurement precision is better than ±1%, the nominal operating pressure is 10 bar, and the burst pressure is greater than 20 bar.
Flow Rate: 5-120 l/min
Nominal Pressure: 10 bar / 145 psi
Viscosity Range: 0.8 – 40 mPa.s
External Thread: 1 in
Partial stored volumes: 8
Measurement precision: ± 1% (after calibration)
Battery: 2 x 1.5 V AAA/LR03 batteries
Battery Life: approx. 5 years
Display: Two-line, LED-illuminated, 6-digit LCD display with a character height of 16 mm (main display)
Operating temperature: -25°C to +55°C
Medium temperature: -10°C to +40°C
Suitable for use with: Diesel/fuel oil, radiator antifreeze, AdBlue® and water
Dimensions (W x D x H): 120 x 52 x 85 mm
Weight: 0.24kg
